Big Baler(1592)

Big Baler Model: 1592

Big Baler Model: 1592

The 1592 baler features a hydraulic plunger system that takes on the toughest baling jobs, including alfalfa, straw, bermuda, sudan, haylage and cornstalks. The exclusive hydraulic drive system uses hydraulic relief valves instead of shear bolts to protect the baler. The feed system is reversible from the tractor seat, saving hours of labor time unplugging the baler.


Height:  10' 0"
Working Width:  10' 0"
Working Height:  9' 8"
Working Length with Bale:  30'
Baler Capacity:  Up to 45 tons per hour
Bale Chamber:  Height: 38"
Width: 46"
Bale Length: Adjustable up to 9'
Bale Weight: Up to 1600 lbs
Plunger:  Speed: Up to 21 Strokes per Minute
Length of Stroke: 30"
Tractor Requirements:  Horsepower: 140 Hp or Greater to PTO recommended
Electrical System: ASAE 7-Pin connector outlet
Hydraulic System: Single remote, pickup lift

Note: Specifications are subject to change without notice or obligation. Please consult your dealer for details.

Standard Equipment

  • Bale chamber size: 38" x 46"
  • 6 conventional twine knotters
  • Hydraulically driven plunger strokes only when bale chamber is fully charged
  • 80 gpm Sundstrand main hydraulic pump
  • Pickup inside width-93 inches (2.36 meters)
  • Windguard for pickup, pickup mounted
  • 1-3/4" 20 Spline 3 joint drive line
  • Reversible feeder crank and pickup from tractor seat
  • Remote control system for independent operation of feed fork
  • Pickup area lights, knotter light, rear lights red and amber rear warning lights
  • Knotter ties monitored by electric operated knot sensors
  • 12 volt group 24 battery
  • Automatic oil luber for knotters
  • Dual knotter fans
  • Automatic hydraulic bale chamber tension control
  • Baler tire size: 23.1 x 26, 12 ply
  • Pickup tire size: 4.80 x 8, 4 ply
  • Two piece drawbar-standard with standard tail chute
  • (see specification sheet for more features)


  • Preserves original hay quality better than the gear-driven baler.

  • Ensures that hay flows freely from the windrow through the feed chute directly into the bale chamber, without the use of a pre-compression chamber.

  • Hydraulically driven bale plunger only operates when the bale chamber is fully charged.

  • Bales up to 45 Tons per hour.

  • Makes a uniform, compact 38" x 46" bale.
  • The 38" height allows three high stacking during transportation.


  • Less tail chute
  • Roller tail chute
  • 34.5" x 46" bale chamber kit
  • Front panel tension gauge
  • Twine box dividers for use of unboxed balls of twine
  • Bale accumulator hitch assy complete-Hesston
