Wagner Steel Workers

Similar in design to our Wagner Logstackers, well known for their capacity and long-lived durability, the Wagner Steelworker offers many of the same features and reliability to the steel scrap handling industry. Features like tricycle design rear tiller steering for an excellent turning radius. Plus Heavy Duty Double Reduction Planetary Axles and Wet Brakes, Selectable Automatic Transmission, a variety of magnetic head options, and an optional Scania Tier 4 engine without a DPF (Diesel Particulate Filter) or high heat regeneration cycle for years of productivity with low operating costs.

Facebook logo - Allied Systems Facebook page   LinkedIn logo - Allied Systems LinkedIn page
Features

Selectable Automatic Transmission

In-Cab Monitors

Hydraulic Braking System

Heavy-Duty Double Reduction Planetary Axles

Force-Cooled Wet-Disc Brakes

Dual Front Tires

Advantages

Capacity: up to 100,000 lbs

Tight Turning Radius

Options

Tier 4 Final Engine without DPF or Regeneration

Engine and Hydraulic Tank Heaters

Auto Lubrication System

Fire Suppression System

Customized attachmets

And Many More

Model Capacity lbs [kg] Max Speed Fully Loaded mph [km/h] Overall Length
ft [mm]
Overall Width
ft [mm]
Height to Cab
ft [mm]
Overall Turning Radius ft [mm]
SW-100 100,000
[45,360]
11.8
[18.99]
45'
[13,716]
14'10"
[4,419]
17'4"
[5,283]
35'6"
[10,820]
Note:
Values in this table are approximate.
Specifications are subject to change without notice or obligation.
