Welcome to the Vault

About

Due to the increasing demand for Allied Marine Crane design information, we have developed a unique online resource for naval architects and designers to quickly gain access to Allied's design portfolio.

Once you have received access, you will be able to review and download both 2D and 3D models at your leisure. In addition to the models, the technical and design specifications are also available through this online database.

We optimized our 3D models for use in large assemblies by simplifying them into models that are all less than 3 MB in size.

We are excited to be able to offer this tool and look forward to working with you in the future.

How to Access

  • Acquire log-in information from Adam Quint (see contact section).

  • Click the link below for access.

  • Proceed with specified log-in information.

  • Choose from specification sheets, 2-D (.dwg) files and 3-D (.stp) files.

    • Contact

    Adam Quint

    E:Adam.Quint@AlliedSystems.com

    P:503.825.3443

    Click Here to Access Vault »
