Freeman WE-4 & WE-5 Water Extractor

Freeman water extractors are the quick and efficient way to extract water from food processor’s waste products, pulp slurries, and other waste products that contain excess liquid.

The steady hydraulic pressure forces moisture out of weep holes in the long extrusion chamber. The top feed incorporates an electronic level sensor which, when it detects a full feed charge, cycles the plunger to allow material to flow to the chamber, then continuously exerts pressure on the load, removing the excess liquid. This is a continuous process which requires no labor.

For more information, take a look at the Water Extractor brochure. Or, click here to request additional information.

Features WE-4 WE-5
Chamber Size:   24" x 24" 40" x 32"
Platen Force:    39,800 lbs 84,800 lbs
Motor:    240/440, 40 HP 240/440, 75 HP
Approximate Capacity @ 8 strokes/minute:    4000 ft^3/hr 7800 ft^3/hr
