Wagner Coil Handlers

Handling steel coils quickly and efficiently has never been easier than with a Wagner Coil Handler. Available in capacities up to 60 tons with optional chassis and probe styles, the Wagner Coil Handlers offer a tight turning radius, a Selectable Automatic Transmission, Heavy Duty Double Reduction Planetary Axles and Wet Brakes for long service life and lowest operating cost, and an optional Scania Tier 4 engine without a DPF (Diesel Particulate Filter) or regeneration cycle.


Features

In-Cab Monitors

Heavy-Duty Double Reduction Planetary Axles

Hydraulic Braking System

Tight Turning Radius

Capacity: up to 160,000 lbs

Options

Tier 4 Final Engine without DPF or Regeneration

Engine and Hydraulic Tank Heaters

Auto Lubrication System

Fire Suppression System

Customized attachments

And Many More

Model Capacity lbs [kg] Max Speed Fully Loaded mph [km/h] Overall Length
ft [mm]
Overall Width
ft [mm]
Height to Cab
ft [mm]
Overall Turning Radius ft [mm]
CP-120 120,000
[54,431]
13.6
[21.89]
35'6"
[10,820]
15'1"
[4,597]
13'4"
[4,064]
26'6"
[8,077]
CP-160 160,000
[72,575]
13.6
[21.89]
36'7"
[11,151]
15'4"
[4,674]
13'4"
[4,064]
22'8"
[6,908]
SW-1000 100,000
[45,360]
11.2
[18.02]
33'9"
[10,287]
14'8"
[4,470]
17'4"
[5,283]
28'3"
[8,610]
Note:
Values in this table are approximate.
Specifications are subject to change without notice or obligation.
