Freeman 370 Pull-Type Baler

Options

  • Hay saver wheel*
  • Pickup depth wheel
  • Electric pickup lift, engine drive baler
  • Electric pickup lift for PTO drive baler
  • Ball type hitch in lieu of standard pin hitch*
  • Hydraulic swing hitch
  • Heavy duty battery for Deutz, Cummins  and Wisconsin engines*
  • Bale weight indicator, hood mount*
  • Flat chute attachment
  • Goose neck hitch
  • Automatic power operated knotter luber*
  • Air blower for knotters*
  • 12 compartment twine box in lieu of standard 9 compartment*
  • Auto tension release during tie cycle for twine tie balers
  • Tandem tension assembly w/3 hydraulic rams
  • Tandem tension assembly w/4 rams

* These items are standard on the Model 380 and 385

**Left & Right hand tire & wheel options available upon request**


Freeman

Freeman 280/285/380/385 Pull-Type Baler

The new line of Freeman model 280/285/380/385 three-tie pull-type balers are similar to the model 270/370, but with added features to make it an even more user-friendly machine.

The new Remote Control provides easy operation for various baling functions from the tractor, including pickup height, drawbar position, bale density and baler operating speed. The Remote Control also provides a digital display of the bale count, fuel level, plunger strokes per minute and plunger strokes per bale.

For more information, take a look at the brochure.

Specifications

Weight: 8,200  to 8,600 lbs.
Overall Width, Single-Wheels: Up to 11' 1"
Overall Width, Tandem-Wheels: Up to 12' 2"
Overall Height: 5' 6"
Bale Weight: 60 to 120 lbs.
Bale Length: Adjustable
Cross Section: 14" x 18", 14" x 22", 15" x 22", 16" x 18", 16" x 22", 17" x 22"
Pickup Width: Up to 70"
Power: 3 Cyl. Deutz, 4 Cyl. Deutz, and Hydraulic PTO
Strokes Per Minute: 84

Standard Equipment

  • Left side tires: Tandem implement tires, 8 ply, 8 hole wheels & heavy hubs
  • Right side tire: Single implement tire, 8ply, 8 hole wheels & heavy hubs
  • Lights: 1 pickup light, 2 white rear lights & 1 red tail light
  • Hour meter, oil and amp warning lights for Deutz engines
  • Heavy duty pump-type bull gear luber
  • Bale chute: Combination L.H. or R.H. turning
  • 30 gallon fuel tank
  • "Super Sweep" Pickup
